HAN'S G3015F

Technical Specification

Performance Parameter HAN'S G3015F
Process size (L x W)  3000 mm x 1500 mm
X axis stroke  3050 mm
Y axis stroke  1525 mm
Z axis stroke  120 mm
Positioning accuracy of X, Y axis  +0.03 mm
Repeat location accuracy of X, Y axis  +0.02 mm
Max. positioning speed  169m/min
Weight of CNC laser cutter  10 T
X/Y axis max. acceleration  1.5 G
Max. lod of worktable  900 kg
Phase  3
Rating voltage of power supply  380 V
Frequency  50 Hz/60 Hz
 Power supply protection level IP54
